"master.. master.. just call my name, 'cause I'll hear you scream" (Metallica - master of puppets)

In my previous entry I covered the design of setting up a cluster of Raspberry Pi devices to build a cheap supercomputer. Hopefully you have got a number of devices configured with the latest raspbian image and it is completely up-to-date. We will start with the master node of the cluster - tweaking the stock image to serve it's purpose.

The master node has the responsibility of providing a number of functions; such as access to the internet, acting as a gateway for the slave nodes and a shared disk drive resource across all the nodes. It is effectively the brain of the system and will draw more power than the slaves so it is recommended to connect it to a higher ampere power to make sure it remains stable.

The Raspberry Pi 3 has two default network interfaces, namely eth0 and wlan0 - for older devices, a USB WiFi adapter would be required. The WiFi network will connect to the internet; while our ethernet network create a private network allowing the slaves to communicate with each other.

Configuring WiFi requires the editing of the following file:

    $ sudo vi /etc/wpa_supplicant/wpa_supplicant.conf

Of course the appropriate settings specific to your WiFi network should be defined here - be careful following older guides online as the jessie release of rasbian has introduced a number of changes which will not work with old guides anymore - this has fueled frustration in the community.

Our design dictated a private network between the master and slave nodes to allow for communication - yet, isolate them from external tampering. In effect; we are building a firewall to protect the nodes. To nerd out the configuration, we will use the 3.141.59.x (π) IP address range.

In summary; these will be the associated IP addresses:

    master: wlan0: 192.168.1.xxx
    slave1: eth0:
    slave2: eth0:
    slave3: eth0:

Our WiFi network should already be setup - your IP address may differ depending on your WiFi network configuration. Now we need to assign a fixed IP address to the eth0 network adapter. In order to do this; we need to modify the DHCP client settings by editing the following file:

    $ sudo vi /etc/dhcpcd.conf
    interface eth0
    static ip_address=
    static domain_name_servers=

We do not want to define a router in this case; as we want it to default to the wlan0 interface. In order for the device to act as a gateway we also need to enable packet forwarding and define NAT routing rules for the eth0 network to utilize the wlan0 network by doing a few simple modifications:

    $ sudo vi /etc/sysctl.conf
    $ sudo vi /etc/rc.local
    /sbin/iptables --table nat -A POSTROUTING -o wlan0 -j MASQUERADE

While we are at it; we might as well create some alias's for the nodes:

    $ sudo vi /etc/hosts     rPi01     rPi02     rPi03     rPi04

Make sure there are not duplicates in this file for hosts - you will need to remove the entry for the current host. We will come back to configuring the slave nodes later on; but we should have everything we needed configured for networking at this point.

To make the supercomputer more like a standard computer we need to have a shared disk drive mapped across all the nodes. This can be useful for loading resources for processing and storing results for all nodes to access; we will utilize NFS to share a USB drive across the nodes.

We should format the USB drive to use the native ext4 file system:

    $ sudo mkfs.ext4 /dev/sda1 -L shared

We need a mount point for the USB drive - we will use /mnt/usb and define it as follows:

    $ sudo mkdir /mnt/usb
    $ sudo mount /dev/sda1 /mnt/usb
    $ sudo chown -R pi:pi /mnt/usb

We need to change the ownership of the mount point to pi:pi so the default user can read and modify files. To make sure the USB drive mounts on boot; we need an fstab entry defined:

    $ vi /etc/fstab
    /dev/sda1 /mnt/usb ext4 defaults,user,exec 0 1

We will now need to install an NFS server so it can be available for other nodes:

    $ sudo apt-get install nfs-server

In order to grant permission to the slave nodes; we will need to define some exports:

    $ sudo vi /etc/exports
    /mnt/usb rpi02(rw,sync)
    /mnt/usb rpi03(rw,sync)
    /mnt/usb rpi04(rw,sync)

The next is to ensure the service starts automatically on boot, and define a symlink for consistency.

    $ sudo update-rc.d rpcbind enable
    $ sudo update-rc.d nfs-common enable

Unfortunately; there is a weird race-condition between the NFS server and RPC; so we need to manually force restart of the nfs-kernel-server on device boot to make sure nfsd is running.

    $ vi /etc/rc.local
    # need to give nfs-server a little nudge to start right
    service nfs-kernel-server restart

We should make an alias for the mount point so that it looks like same as it will on a slave node.

    $ sudo ln -s /mnt/usb /mnt/nfs

This will allow us to run applications on the master node using the binaries as on the slaves without conditional compilation rules when trying to access the shared mounted resource.

We will also want to initialize some ssh keys so that we have a mechanism to log in and out of the slave nodes without having to provide a password every time. This will be vital when we look at utilizing software in the future to run parallel applications on the device smoothly.

    $ mkdir ~/.ssh
    $ cd ~/.ssh/
    $ ssh-keygen

We will come back to deploying the id_rsa.pub file across the slave nodes when we set them up. A final task is to provide an easy way to shutdown all the slave nodes from the master:

    $ vi shutdown.sh
    HOSTS="rpi04 rpi03 rpi02"
    for HOSTNAME in $HOSTS; do
        echo executing \'sudo shutdown -hP now\' on $HOSTNAME
        ssh `whoami`@$HOSTNAME sudo shutdown -hP now
    echo executing \'sudo shutdown -hP now\' on localhost
    sudo shutdown -hP now

We have learnt in the past that failure to power down a Raspberry Pi device can end up with a corrupt file system on the memory card - it would not make sense to manually log into each slave to shut them down so this script will come in handy - it can be easily modified to reboot the slaves.

We can do a few sanity checks to make sure everything has been done right:

    # verify the IP addresses on the network interfaces
    $ ifconfig
    eth0  Link encap:Ethernet     HWaddr b8:27:eb:2d:a1:0f
          inet addr:    Bcast:   Mask:
    wlan0 Link encap:Ethernet     HWaddr b8:27:eb:78:f4:5a
          inet addr:192.168.1.xxx Bcast:  Mask:
    # verify the mount point has been defined right
    $ ls -al /mnt
    total 12
    drwxr-xr-x  3 root root 4096 Nov 26 12:48 .
    drwxr-xr-x 22 root root 4096 Nov 26 13:43 ..
    lrwxrwxrwx  1 root root    3 Nov 26 12:48 nfs -> usb
    drwxr-xr-x  3 pi   pi   4096 Nov 26 12:49 usb
    # verify nfsd is running
    $ ps -aux | grep nfsd | wc -l
    root 776 0.0 0.0    0     0 ?     S< 19:00 0:00 [nfsd4_callbacks]
    root 779 0.0 0.0    0     0 ?     S  19:00 0:00 [nfsd]
    root 780 0.0 0.0    0     0 ?     S  19:00 0:00 [nfsd]
    root 781 0.0 0.0    0     0 ?     S  19:00 0:00 [nfsd]
    root 782 0.0 0.0    0     0 ?     S  19:00 0:00 [nfsd]
    root 783 0.0 0.0    0     0 ?     S  19:00 0:00 [nfsd]
    root 784 0.0 0.0    0     0 ?     S  19:00 0:00 [nfsd]
    root 785 0.0 0.0    0     0 ?     S  19:00 0:00 [nfsd]
    root 786 0.0 0.0    0     0 ?     S  19:00 0:00 [nfsd]
    pi   968 0.0 0.1 4276  1840 pts/0 S+ 19:04 0:00 grep nfsd

In the next entry; we will configure the slave nodes and verify that everything is working!
