This was a project from day one we weren't even sure would be possible to do - persistence prevails!

With the last few blog entries I have covered the design and evolution of the µTLS (micro TLS) project with the aim to bring a feasible security protocol to low powered micro-controllers with limited resources. From design, through implementation, tweaks, refactoring and integration into an existing deployment - we now have a solid foundation to build on that accomplishes the initial goals defined.

The Arduino UNO was the primary target for µTLS (micro TLS) due to its limited resources an widespread adoption within the hobby IoT environment - it has become a platform known as the birthplace for numerous IoT projects with breadboards and jumper wires going crazy that eventually gets replaced by a custom PCB as ideas become reality and hit production phase.

Does it really make sense to throw in a higher powered ARM or X86 micro-controller when it isn't required? It comes down to being lazy - it is easier to throw together a Linux based micro-controller instead of writing barebones firmware for a low-powered micro-controller - which compound additional security issues to the product and have higher power demands; as well as increasing operational costs.

In reality; most IoT products are pretty dumb. They have simple tasks; such as reading a few sensors; trip a few GPIO's to control relay or switches and periodically check in with a server to upload data or receive instructions to perform specific operations. Product design for the embedded space can be costly - for most, it is who gets to the market first, security and data integrity comes second.

µTLS (micro TLS) was created to prove to the community that security and data integrity is feasible; without having to sacrifice power and costly components - and more importantly open a pandoras box of issues these systems inherit as a result. There is no reason to do so - and here we have proof.

It is time for IoT product manufacturers to stop being lazy and bring the right people into the job when designing products. "Real programmers" are a dying breed these days - IoT has forced developers to think about memory and performance, not encourage bloatware and just throwing together a heap of third party libraries. As unfortunate as it sounds; this is the reality these days.

To finish off the µTLS (micro TLS) series - it is only fitting to define some metrics for what has been achieved so far. With these facts presented; we do hope that the excuse of not having security being low-power and limited resources be thrown out the window - and lay off any engineer who claims that.

When targetting the Arduino UNO (16Mhz avr) we see the following memory and resource utilization:

     protocols      program size  mem:entry    mem:peak     mem:diff (entry/peak)
     none-none      16,718 bytes    966 bytes  1,164 bytes
     none-rot13     16,888 bytes    966 bytes  1,164 bytes    0 bytes    0 bytes
     none-xor128    16,960 bytes  1,094 bytes  1,292 bytes  128 bytes  128 bytes
     none-aes128    20,584 bytes    994 bytes  1,234 bytes   28 bytes   70 bytes
     none-aes192    20,600 bytes  1,002 bytes  1,282 bytes   36 bytes  118 bytes
     none-aes256    20,658 bytes  1,010 bytes  1,330 bytes   44 bytes  166 bytes
     none-rc4       18,158 bytes  1,234 bytes  1,786 bytes  268 bytes  622 bytes
     aes128-aes128* 21,030 bytes    994 bytes  1,256 bytes   28 bytes   92 bytes
     ecc163-aes128* 26,262 bytes    994 bytes  1,622 bytes   28 bytes  458 bytes

When targetting the Arduino Due (84Mhz ARM) we see similar memory and resource utilization:

     protocol       program size  mem:entry    mem:peak    mem:diff (entry/peak)
     none-none      21,828 bytes  5,688 bytes  5,912 bytes
     none-rot13     21,948 bytes  5,688 bytes  5,912 bytes   0 bytes    0 bytes
     none-xor128    21,988 bytes  5,816 bytes  6,040 bytes 128 bytes  128 bytes
     none-aes128    24,492 bytes  5,724 bytes  6,028 bytes  36 bytes  116 bytes
     none-aes192    24,500 bytes  5,732 bytes  6,076 bytes  44 bytes  164 bytes
     none-aes256    24,540 bytes  5,740 bytes  6,124 bytes  52 bytes  212 bytes
     none-rc4       22,692 bytes  5,964 bytes  6,532 bytes 276 bytes  620 bytes
     aes128-aes128* 24,716 bytes  5,724 bytes  6,076 bytes  36 bytes  164 bytes
     ecc163-aes128* 27,508 bytes  5,724 bytes  6,452 bytes  36 bytes  540 bytes

The figures presented include a full application sketch for the initialization and operation of a µTLS (micro TLS) client. All core logic dealing with connection establishment to a µTLS (micro TLS) server, authentication, identification, key exchange and on-going communication over the HTTP protocol.

Also included is the system memory required for the Serial and networking (WiFi or Ethernet) libraries - in addition to a 512 byte shared memory region known as 'scratch'; which can be resized as needed depending on the target architecture and purpose for the micro-controller. The cases marked with an asterisk ('*') would be considered secure; in alignment to the Transport Layer Security guidelines.

We have demonstrated that even an Arduino UNO can be a secure weather station; and we can target any micro-controller as necessary quite easily - with little or zero modification to our source code. Personally; it is nice to see µTLS (microTLS) working without problems on the particle.io device series.

The full source to the driver routines for each of these modes are provided for reference:

µTLS (micro TLS) will undergo further development - mainly to add additional protocol modules and refine the library to match additional use-cases as we integrate it into some existing IoT projects that we currently have deployed. Parties interested in knowing more about µTLS (micro TLS) and information on licensing should contact us at the link provided below.

It is my hope that 2017 will bring true awareness to IoT security and make sure something is done.
